Just a few wrenches is all you need to install a filter kit on a V25 pump.
Here's 13 steps to install a GPI V25 Fuel Transfer Pump and GPI Filter Kit onto your tank. If you already have the pump with the nozzle holder in place, start at step 7.
Installing a GPI Filter Kit on V25 Fuel Transfer Pump
- Add thread tape to all threaded parts of the pump, hoses, suction pipes and adapters.
- Install the included bung adapter on the suction pipe and extend suction pipe to its full length
- Tightly install the bung adapter on the fuel tank.
- Install the pump on the bung adapter
- Tighten down the spin collar
- Attach the nozzle holder to the pump using a 4 mm hex wrench
- Install the o-ring to the pump outlet
- Install the quick fit filter adapter to the pump outlet using a 5 mm hex wrench
- Install the fuel filter and o-ring onto the adapter
- Attach the hose to the hose adapter
- Install the hose adapter onto the filter adapter with a 5 mm hex wrench
- Tighten the hose into the adapter to prevent leaks and drips
- Attach your nozzle to the hose
Offerings covered by this post:
GPI V25 12V Fuel Transfer Pump Only (25 GPM) – V25-012PO
GPI V25 12V Fuel Transfer Pump, 1″ Manual Nozzle, 18′ Hose & Tank Adapter Mount (25 GPM) – V25-012MD
GPI V25 12V Fuel Transfer Pump, 1″ Auto Nozzle, 18′ Hose & Tank Adapter Mount (25 GPM) – V25-012AD
